Starlink Mini Kit
Key Features
Model: Starlink Mini Kit
Antenna: Electronic Phased Array
Frequency: Dual Band Wi-Fi Generation - Wi-Fi 5
Wi-Fi Coverage (Approximate) - Up to 1200 sq. ft. (Open Space)
Devices - Connect Up to 128 Device
Ethernet Ports: 1x Latching Ethernet LAN port with Starlink Plug
Color - White
Payment Options
Specification
| Key Features | ||
|---|---|---|
| Antenna | Electronic Phased Array | |
| Frequency | Dual Band 3 x 3 MU-MIMO | |
| Wireless | WiFi 5 | |
| Network Standard | 802.11a/b/g/n/ac | |
| Encryption | WPA2 | |
| Ports | 1x Latching Ethernet LAN port with Starlink Plug | |
| Others | Field of View: 110 ° Orientation: Software Assisted Manual Orienting Environmental Rating: IP67 Type 4 with DC Power Cable and Starlink Plug/Cable installed Operating Temperature: -30°C to 50°C (-22°F to 122°F) Wind Speed: Operational: 96 kph+ (60 mph+) Snow Melt Capability: Up to 25mm / hour (1 in / hour) Power Consumption: Average: 25-40W Input Rating: 12-48V 60W (12v short Starlink cable coming soon in Shop) USB PD Requirement: 100W, 20V/5A Minimum (with Starlink USB-C to Barrel Jack Cable Accessory) Coverage: Up to 112 m² (1,200 ft²) Power Indicator: LED | rear face plate, lower left corner Mesh Compatibility: Compatible with all Starlink mesh systems *Not compatible with 3rd party mesh systems Devices: Connect up to 128 devices | |
| Power Source | ||
| Power Mode | 100-240V ~ 1.6A 50 - 60 Hz | |
| Physical Dimension | ||
| Dimension | 298.5 x 259 x 38.5 mm (11.75 x 10.2 x 1.45 in) (Starlink) 91 x 44 x 51 mm (3.6 in x 1.7 in x 2.0 in) (Power Supply) 430 x 334 x 79 mm (16.92 x 13.14 x 3.11 in) (Package) | |
| Weight | 1.10 kg (2.43 lb) (Starlink) 1.16 kg (2.56 lb) with Kickstand (Starlink) 1.53 kg (3.37 lb) with Kickstand & 15 m Cable (Starlink) 0.2 kg (0.44 lbs) (Power Supply) 6.73 kg (14.83 lbs) (Package) | |
| Manufacturer warranty | ||
| Warranty | 1 year official warranty from Starlink. For any warranty claims, please contact Starlink Customer Support directly via the Starlink app. (Star Tech will not be responsible for handling warranty claims.). Subscription Policy: As per Starlink's policy, customers are required to activate their internet subscription by themselves. If you encounter any issues with the subscription, please reach out to Starlink Support via the Starlink app. | |
Starlink Mini Kit
The Starlink Mini Kit is an innovative satellite internet solution. Designed to deliver dependable communication in a variety of settings. This Starlink Mini Kit contains an electronic phased array antenna with a wide field of view of 110 degrees, ensuring optimal signal reception. The orientation is helped by software-assisted manual orientation, which makes setup simple. The Starlink Mini Kit has an IP67 Type 4 environmental classification and is designed to endure tough conditions such as operational wind speeds of over 96 kph (60 mph) and snow melt capabilities of up to 25mm (1 inch) per hour. The Starlink Internet has power consumption ranges from 25 to 40 watts, and with an input rating of 12-48V and a maximum of 60W, this Mini Kit ensures energy efficiency. For individuals who need more power, the Starlink USB-C to Barrel Jack Cable attachment offers a 100W USB PD need at 20V/5A. The Starlink Mini Kit is Wi-Fi technology that supports 802.11a/b/g/n/ac and uses WiFi 5 for improved performance. The dual-band radio has a 3 x 3 MU-MIMO setup, which allows for multiple connections and higher data transmission. The Starlink Mini Kit provides one latching Ethernet LAN connector with a Starlink socket for a dependable connected connection. Coverage is up to 112 m² (1,200 ft²), making it suited for a variety of situations. WPA2 encryption protects user data. The power indicator is conveniently situated in the lower left corner of the LED rear faceplate. Also, the Starlink Mini Kit works with all Starlink mesh systems but does not support third-party mesh systems. Users may connect up to 128 devices, making it an excellent solution for families or small companies looking for reliable internet connectivity.
